柱體端面研磨機

model：BROT10327
Origin：法國
Functional use：
該設備用于柱體巖樣端面的研磨，提供平滑的和平行的端面，在巖心物性測試時非常重要。該設備有一個巖心夾具、支架和頂蓋、一個冷卻液供給系統、冷卻液回收盤和一個金剛石的端面打磨砂輪、一個干磨用的真空吸塵器。巖心夾具可以適合所有尺寸的巖心樣品。

If you are interested in this product, please click on the inquiry

Click to enlarge image

Performance parameters
Others

1、電源：230-380V/50Hz
2、轉速：2950 rpm
3、巖心直徑：φ12 – 38mm
4、砂輪直徑：φ150 mm/ D46，φ150 mm/ D30
5、設備外形尺寸：460 X 400 X 360 mm
6、重量：27kg
